Easy control & high efficiency 50kg dry ice pellet making machine dry ice machine dry ice machine

1.0 Sets
MOQ
Easy control & high efficiency 50kg dry ice pellet making machine dry ice machine dry ice machine
Caratteristiche Galleria Descrizione di prodotto Richieda una citazione
Caratteristiche
Specificazioni
Applicable Industries: Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Restaurant, Retail, Food Shop, Construction works , Food & Beverage Shops, Other
Condition: New
Ice Shape: Granular
Voltage: 380V,50hz,3P/customized
Power: 5.5KW/18.5KW
Dimension(L*W*H): 1600 x 1400x 1700mm
Weight: 800KG
Warranty: 1 Year
Key Selling Points: Professional and reliable products and quality service
Ice storage capacity: 150KG
Machinery Test Report: Provided
Video outgoing-inspection: Provided
Marketing Type: hot selling 2020
Warranty of core components: 6 months
Core Components: Motor, Pump, PLC
Product name: pellet dry ice making machine
Keyword: Dry Ice Maker Equipment
Application: Food, industry, transportation
Ice size: 3-16mm
Type: Automatic Dry Ice Maker
Feature: easy control & high efficiency
Function: Making granular & block dry ice
After-sales Service Provided: Online Support, Free spare parts, Video technical support, Online support
raw material: Liquid Carbon Dioxide
After Warranty Service: Video technical support, Online support, Spare parts, Field maintenance and repair service
Local Service Location: None
Showroom Location: None
Certificazione: ISO /CE
Informazioni di base
Certificazione: ISO /CE
Termini di pagamento e spedizione
Packaging Details: Special wooden box for export (no fumigation required)
Supply Ability: 500 Set/Sets per Month
Descrizione di prodotto

professinal dry ice making machine dry ice maker dry ice pellet machine dry ice pelletizer dry ice granulate machine industrial dry ice machine dry ice machine co2 pelletizer machine

Product Description

1.PLC Omro - controls the complete process, injection and hydraulic

2.lndependent performance-very constant production, independent of pressure and temperature

3.Integrated production control system- definition and supervision of production quantity

4.High process reliability-optimized process monitoring provides optimal performance and increases process reliability

5.Easy maintenance-simple structure and easy replacement of spare parts makes maintenance work simple for even new users

6.Minimum floor space for high production performance

Technical Parameters

Model

FGB-50-1

FGB-100-1

Motor Power(kw)

3.7

5.5

Dry Ice Size (MM)

Inch

Φ3-Φ16

0.1-0.6

Φ3-Φ16

0.1-0.6

Min-Max (kg/h)

50-60

100-120

Raw Materials(t/m³)

1.5

1.5

CO²Transformation rate

38%

38%

Liquid inlet pressure(MPa)

2.1

2.1

Liquid inlet diameter(MM)

DN10

DN10

Exhaust pipe diameter

DN50

DN50

Fuel tankage

90

200

Overall Dimension(CM)

160*80*130

160*140*170

Weight (KG/LBS)

600/1322.76

750/1653.45

Detail pictures show:

Finished different dry ice size picture show:

Packaging & Shipping

#1:The main parts will be wrapped with foam,then put into the carton; the mainbody portion will be packed in wooden cases.
#2: Both neutral and customized packaging can be available.
#3. The most cost-effective method of transportation of machines is sea shipping way. We can also ship the goods to you by International Express such as DHL,UPS,TNT,EMS(Recommend cargo with smaller size and weight),as well as Rail transport and by air ,you can choose the appropriate one based on your timeline and budget freely. Besides, you can also use your own shipping agent.
